Custom prototype 2.54 PIN header metal snap domes membrane foil keypads

FOB Reference Price:Get Latest Price
US $0.88-8.88 / Piece | 10 Piece/Pieces (Min. Order)
Supply Ability:
100000 Piece/Pieces per Month
Report Suspicious Activity
Quick Details
Place of Origin:
Hebei, China (Mainland)
Brand Name:
Model Number:
Telecommunication Equipment
Keypad Button Material:
PVC,PET,PC,Sandwich,Circuit,3M glue
Back adhesive:
prototype 2.54 PIN header metal snap domes membrane foil keypads
metal dome/poly dome
flexible,custom cable length,tracks pitch
printing silver ink on PET material
Screen Printing and 3D digital pringting
2.54mm female connector or 1mm ZIF connector
Packaging & Delivery
Packaging Details
50 pieces in a poly bag then put in carton, or regarding to custoners requirement
Delivery Time
within 5-10days
Product Description

Custom prototype 2.54 PIN header metal snap domes membrane foil keypads

The graphic overlay indicates the location of the keys and is the esthetic component of the keypad or device. MBR selects the best inks and most appropriate materials to manufacture them. Graphic overlays, which are particularly necessary for membrane switches, are also useful for instruments with mechanical keys, product identification, labels, and dashboards.
The image is silk screened and placed behind a transparent surface, ensuring permanent identification.

Raw  Material

Finish of surface
Graphic Overlay
 0.175/.25/.35 mm
0.175/.25/.35 mm
Fine Texture
Valvet Texture
Gloss with Hard Coat
Rear Adhesive
Paper Double-sided Tape

General Specification
Operating Temperature
-20° to 65° C (-4° to 149° F)
Storage Temperature
-40° to 85° C (-40° to 185° F)
3M permanent acrylic adhesive resists against dust, water, oil and moisture conditions.
Special sealing options are available for wet environments.
.007 inches to .015 inches
Operating Force
4oz to 8oz
Operating Voltage
30 volts maximum
Operating Current
10 microamps to 100 milliamps, resistive
Closed Circuit Resistance
100 ohms typical, dependent on size and layout
Open Circuit Resistance
10 megohms
Operating Power
1 watt maximum
X-Y matrix or one side common

Technology Process
Related Products

embedded LED membrane switch / keyboard / keypads

4 x 4 Matrix Array 16 Key Membrane Switch Keypad Keyboard

Membrane Swith Front Panel Graphic Overlay
