4*5 Matrix Array/Matrix Keyboard 20 Keys Custom Membrane Switch Keypads

FOB Reference Price:Get Latest Price
$0.59 - $5.95 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Hebei, China (Mainland), Hebei, China
Brand Name:
MBR, MBR
Model Number:
MBR-CL030
Application:
Telecommunication Equipment
Keypad Button Material:
PET/PC
Color:
Pantone
Material:
PET PC
Size:
Customized Size
Life Expectancy:
1 Million Times
Certification:
ISO9000
Type:
Meet Customer's Demand
Feature:
Water-proof/Durable
Dome:
Metal Dome/Poly Dome
Supply Ability
Supply Ability:
100000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Minimum Order Quantity :10 pieces;
Packaging Details:PE bag, Carton, Wooden crate.
Port
Beijing
Lead Time :
10-15days
Video Description
Product Details

4*5 Matrix Array/Matrix Keyboard 20 Keys Custom Membrane Switch Keypads

1.Graphic Overlay– PET/PC is usually the material of choice due to its superior chemical resistance and flex life . MEIBORUI can either digitally print, screen-print, or employ a combination of both methods to ensure you get the right colors, textures and finishes your design requires.

2.Overlay Adhesive – This adhesive layer bonds the graphic overlay to the top circuit layer, and is typically an acrylic adhesive. The material is same as the fourth layer. Only the thickness will be different according to the physical truth.

3.Top Circuit Layer – The material of this layer is special. This is a 0.1mm heat stabilized PET printed with silver-filled electrically conductive inks and also dielectric inks, which used for fastening metal domes.

4.Circuit Spacer – This layer separates the top circuit from the bottom circuit so the switch remains normally open until the keypad is pressed. The circuit spacer is a polyester spacer with adhesive on both sides.

5.Lower Circuit Layer – This layer is a 0.1mm--0.25mm heat stabilized polyester printed with silver-filled electrically conductive inks and also dielectric inks. This layer terminates as a flexible tail that serves as the interconnect to controller PCBs or other electronics.

6.Rear Adhesive Layer – This adhesive layer bonds the entire membrane switch package to the product enclosure, housing, or to a rigid support panel. MEIBORUI can specify the appropriate adhesive type and thickness to bond your membrane keypad to your equipment.

Product Parameters
Name
Specification
Name
Specification
Wire lead resistance
<1Ω/cm
Insulation resistance
<100mΩ, 250V DC
Operating temperature
at 40°C, <98% RH
Switch travel
flat type 0.05-0.3mm
Rated voltage
<50V DC
Tactile type
0.3-1.0mm
Product Details Show
Product Packing

Packing products


transportation products


reach destinations


Why Choose Us

About us

27 years of export experience along with excellent quality, advanced services and competitive prices, MEIBORUI has won numerous customers' trust and support.


Reputation

Recently we get the high reputation and the certificate of Small and Medium High-tech Company of Hebei Province was awarded by the Science and Technology Office of Hebei Province.

Product Service

If any quality problem happened within a year, you can return the goods. If quality problem happened when delivery, you can return the goods in no reason.

FAQ

Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent,
we can pack the goods in your branded boxes after getting your authorization letters.

Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.

Q3. What is your terms of delivery?
A: DHL, TNT USP etc.

Q4. How about your delivery time?
A: Honestly, it depends on the order quantity and the season you place the order. The lead time of MOQ is about 10 to 15 days. Generally speaking, all of the goods can be reach your address within 4 weeks.

Q5. Can you produce according to the samples?
A:Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

Q6. What is your sample policy?
A: e can supply the sample , but the customers have to pay the sample cost and the courier cost.


Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery

Q8: How do you make our business long-term and good relationship?
A:.We keep good quality and competitive price to ensure our customers benefit ; We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.

If you have another questions,please contact us.
